Class 1 Nova – Laser System

Class 1 laser cutter comes with the same features as Nova laser cutter such as motorized table, Hybrid servo motor, air assist, smart board etc. And the main difference is that the Class 1 safty systems have safety circuit, which is designed to meet CE Class 1 standard. It will cut the power supply when users were detected to use the laser improperly. If your circumstance requires a safer laser machine, this model can meet your needs.

Machine Details

Standard Features

Hybrid servo motor

1000mm/s speed for engraving photo, super smooth vector cutting quality.

Smart board

Control the exhaust fan,air assist, and alarm lamp automaticly, energy saving

Laser software

RDWorksV8 laser software.

LCD panel

Set speed, power, and more directly from the LCD panel.

Auto focus

Help the user to set focus Easier. (based on motorized table)

Motorized table

Control the table up/down from LCD panel directly

Honey comb table

Reduces underside reflections.

Aluminum blade cutting table

Reduce the influence of the reflection of laser.

3D Engrave

Engrave high quality 3D photos directly.

3D cutting

Achieve “3D cutting” on some materials

Parameter library

Help you to save times.

Color mapping

Change the working speeds and power by using color settings.

Visible Red Dot Pointer

Make the laser beam “visible”.

High quality laser tube

Every laser tube must pass the strict quality control test.

High quality optics

High quality optics.

Mirror mount

Thunderlaser easily re-adjusting 3D mirror mounts.

Connection ways

High-speed Ethernet line or the USB cable line.

USB disk interface

Thunder laser system supports the USB disk loading.

Free Home position

Freely change the starting position.

Large buffer memory

You can take the file directly from the memory.

Emergency stop

Turn off the machine immediately when there is an accident.

Open flap protection

Laser will stop working if you open the front cover.

Water protection

Laser will stop working if the water cooling system is not working

Alarm Lamp

Show the work state and tell when the job is done, more safe for you.

Standard laser head

It is the most often used head.

Air assist

Blowing air to prevent the material being burned

The strong machine case

Improve the laser machine performance.

Exhaust system

Ensure the work pieces and laser cutter machine inside be clean.

Drive belts

This belt is stable performance with long life, wearable and durable.

Low-noise cooling fan

Operate the laser in a quiet and comfortable surroundings.

High quality rails

Keep the engraving/cutting precise and very durable.

Technical Specifications

Laser System		NOVA 24 Class 1	NOVA 35 Class 1	NOVA 51 Class 1	NOVA 63 Class 1
Laser Tube Wattage		40-60Watt	80-130Watt	100-130Watt	100-150Watt
Work Area		600x400mm(23.6″ x 15.7″)	900x600mm(35.4″ x 23.6″)	1300x900mm(51.2″x35.4″)	1600x1000mm(63.0″x39.4″)
Max Part Size (WxLxH)	Front door closed	700x530x170mm(27.6″ x 20.9″ x6.7″)	1000x730x230mm(39.4″ x 28.7″ x9.0″)	1400x1030x230mm(55.1″ x 40.6″ x9.0″)	1700x1130x230mm(66.9″ x 44.5″ x9.0″)
	Pass-through door	700x∞x15mm(27.6″ x ∞” x 0.6″)	1000x∞x20mm(39.4″ x ∞” x0.8″)	1400x∞x20mm(55.1″ x ∞” x0.8″)	1700x∞x20mm(66.9″ x ∞” x0.8″)
Table Size		700x530mm(27.6″ x 20.9″)	1000x730mm(39.4″ x 28.7″)	1400x1030mm(55.1″ x40.6″)	1700x1130mm(66.9″ x 44.5″)
Z Axis Height		155mm(6.1″)	230mm(9.1″)	230mm(9.1″)	230mm(9.1″)
Dimensions(WxDxH)		1070x790x610mm(42.1″ x 31.1″ x24″)	1500x1105x1040mm(59.1″ x 43.5″ x40.9″)	1900x1405x1040mm(74.8″ x 55.3″ x40.9″)	2200x1505x1040mm(86.6″ x 59.3″ x40.9″)
Net Weight		130kgs(287lbs)	310kgs(683lbs)	430kgs(948lbs)	470kgs(1036lbs)
Laser Type		Sealed Co2 Glass Laser Tube
Cooling		Water Cooled
Motion Control System		High-Speed Hybrid servo motor
Maximum Speed		1000mm/S(39.4 IPS)
Speed and Power Control (engraving depth)		Computer or manually controlled speed and power from 0-100%. Vector color mapping sets speed and power settings using RGB color mapping.
Operating Modes		Optimized raster, vector, and combined mode
Resolution(DPI)		User controlled from 100 to 500DPI(standard laser head), up to 1000 DPI(HR head)
Computer Interface		Ethernet and USB Connection
Compatible Operating Systems		Windows XP/2000/Vista/7/8/10
Buffer Memory		128MB Standard
Display Panel		3.5″ LCD panel showing current file, total working time, laser power, speed etc.
Electrical Requirements		110 to 240 volts, 50 or 60 Hz, single phase
Ventilation System		Integral exhaust fan.There is 1 output port, 5.7″ (145 mm) in diameter in the rear of the case.
Standard Features		Red dot pointer, Auto focus, Motorized table, Pass-through Door, Air Assist, Water pump ,Exhaust fan, HoneyComb Table, 2″ (50.8 mm) Focus Lens, Easily adjustable Home position, LCD Display,3D Engraving ,”No water” protection, Emergency stop, Maintenance mode, Open cover protection,Hybrid servo motor
Optional Features
High Resolution Head		Increase the resolution up to 1000DPI
Rotary Axis		Use to engrave on round items
Water Chiller		Improve the cooling of laser tube

Machine Size

nova35 size

nova35-100w size

nova51 size

nova63 size

Optional Items

Water Chiller
When the laser tube is working, it will produce a large amount of heat.Since the water chiller has the refrigerating capacity and can adjust the temperature intelligently to keep the temperature within a certain range, there by to ensure the stability of laser working.

Rotary Axis

Rotary engraving equipment was used to extending THUNDERLASER system application, as a optional component, It can be used for cutting and engraving round items…

Heat Alarm Detector
A thermal detector is designed for areas where a fire will be more flame and heat than smoke; areas such as laser cutter and engraver, kitchens, garages and workshops. The small thermal heat detector will also have a 10 year, long life battery…

HR laser head

We named Hight-Resolution head as HR head for short,it’s made by special structure for focusing the laser bean into a much smaller dot,thus we can get more tiny laser dots in a unit area,and the engraving result will be more elaborate…

4″ laser head

4″ laser head owns a longer focal distance than 2″ standard head, thus for cutting thick material, it makes the cutting edge more smooth and straight…

Air compressor

The high pressure and low noise air compressor offered by Thunder Laser co2 laser engraving machine includes two parts: the high pressure and low noise air compressor and the water separator…

Materials

If your material is not in the below list, our Applications Team would be happy to assist you to test it.

Materials	Engrave	Cut
Wood	√	√
Acrylic	√	√
Delrin	√	√
Cloth	√	√
Leather	√	√
Mat Board	√	√
Melamine	√	√
Paper	√	√
Mylar	√	√
Pressboard	√	√
Rubber	√	√
Wood Veneer	√	√
Fiberglass	√	√
Plastic	√	√
Cork	√	√
Corian	√	√
Twill	√	√
Anodized Aluminum	√	X
Painted Metals	√	X
Tile	√	X
Glass	√	X
Coated Metals	√	X
Ceramics	√	X
Marble	√	X
Stainless Steel	*	X
Brass	*	X
Titanium	*	X
Bare Metal	*	X

* means the laser cannot engrave directly, you will need the help of the “thermark spray”, you can visit www.thermark.com for more information.

Video

Machine Guiding Video

How to choose a reliable laser cutter

WATCH NOW

▷ How to choose a reliable laser cutter
Machine Guiding Video

How to setup your nova laser cutter

WATCH NOW

▷ How to setup your nova laser cutter
Machine Guiding Video

DPES Sign Fair with Thunderlaser in 2016

WATCH NOW

▷ DPES Sign Fair with Thunderlaser in 2016
Machine Guiding Video

How to install HR head

WATCH NOW

▷ How to install HR head
Machine Guiding Video

Auto focus

WATCH NOW

▷ Auto focus
Machine Guiding Video

How the Mars Motorized table works

WATCH NOW

▷ How the Mars Motorized table works

FAQ

1.Do I have to record all the cutting/engraving parameters for different materials in a paper?

No need. We’ve added a parameter library in the software, once you find out what settings is best for a certain material;you can record it in the parameter library. Next time you cut the same material, you just need to read it from the list.

2.Does your laser run from a laptop or Desktop PC?

Both ok, as long as your operating system is Windows XP/2000/Vista/7/8/10.

3.Does your laser run in Windows XP?

Our laser runs on Windows XP/2000/Vista/7/8/10 both 32bits and 64bits system.But it does not run on Mac OS.

4.What software is suggested to design my jobs?

CorelDraw and AutoCAD are suggested. You can design all your artworks in these two software and then send to the RDWorks software to set the parameters easily.

5.What files is the software compatible with?

JPG, PNG, BMP, PLT, DST, DXF, CDR, AI, DSB, GIF, MNG, TIF, TGA,PCX, JP2, JPC, PGX, RAS, PNM, SKA, RAW

6.Will it engrave from a jpeg image?

Yes.

7.Can I take a picture and engrave the image on an object without any hassles?

Yes, you can take a photo by using a camera and then load the photo to the software directly and engrave it.

8.Does machine comes ready to work?

the laser machine is ready to work, the exhaust fan and the air pump and the water pump are included. (But when you using a big power laser tube, it is suggested to buy a water chiller for cooling the laser tube)

https://www.thunderlaser.com.au/how-to-use-your-laser-machine/how-to-setup-your-mini60-laser-system.html

https://www.thunderlaser.com.au/how-to-use-your-laser-machine/how-to-setup-your-nova-laser-cutter.html

9.How much time do I need to spend on learning how to run the laser machine?

As long as you know how to design jobs in graphic software, it just takes a few hours for you to become a master of laser machine. You just need to do some tests to know what speed and power is good for different materials. Since we’ve provided some of the parameter library, it will save you more time.You can watch the guiding videos from our website to learn how to use the machine in advance too.
